Patchwork 3D


Discover the main benefits of the Patchwork 3D software.

Presentation

From real time to physico-realistic

In Patchwork 3D, you have at your disposal three rendering engines, from the fastest to the most realistic: Interactive OpenGL, Ray Tracing and Iray physico-realism.

Variations

Our software allows you to easily create an infinite combination of variants from a CAD model by modifying shapes, positions, materials, the environment, lights…

These configurations can be recalled in an instant and used to develop a whole range of products. Arrange elements on aspect layers and they become combinable at will.

Realistic materials

Material features such as multi-layers, stickers, Parallax Bump Mapping and the text generator allow you to achieve highly detailed results. AxF scanned materials and the Car Paint function reproduce real materials even more faithfully.

Materials are defined in metric units, hence they are reusable and compliant on all your products for predictable results. The powerful Stitching Workshop help you to create very realistic seams easily in a few minutes.

… and very easy positionable

Our UV unfolding technology is the most precise and easy to use. It is used to flatten the surfaces of your 3D models and control the behavior of the materials applied to them very precisely: follow the contours, visualize the constraints and orient them in a few clicks.

Patterns can be exported to create custom texture images.

Lights and decorations

A complete palette of tools allows you to define lighting ambiances: omnidirectional source, spots, extended lights, sunlight and HDRI environments will make your scenes even more realistic. Import photo-realistic HDRI 3D sceneries corresponding to the environment and get an amazing immersion of your product.

Still, animated or interactive images

Produce images to share, and record videos of your products with cinematic animations, camera movements, and even material variations.

You can also use 3D data to create scenarios and respond to user interactions in our computer, mobile and web-based viewers. Rotate the product, compare several variants, trigger animations, configuration changes…

In short, present your CAD models in a new light anywhere.
